recycling machine
a PE PP Film and Woven Bag Pelletizing Line, a specialized industrial setup for recycling polyethylene and polypropylene materials. It begins with a depiction of the raw material in its initial and processed granular forms on the left. The process flow moves from left to right, showcasing the various machinery involved: starting with a material feeding system, followed by a crushing or grinding unit in red and blue, then an advanced processing machine in white and blue equipped with control systems. Finally, the line includes a pelletizing unit where the processed material is formed into pellets, indicated by a hopper and a collection system to the far right. This layout effectively demonstrates the transformation of waste materials into reusable plastic pellets, highlighting the recycling capabilities of the equipment.

Single Stage PP/PE Film/Bags Pelletizing Line

TECHNICAL SPECIFICATIONS

ModelRMC2-85RMC2-100RMC2-120RMC2-150RMC2-160RMC2-180
Capacity(KG/H)100-200200-300300-400500-600700-800800-1000
L/D1:331:331:331:361:361:36
Install Power(KW)110135160310370520
Compactor Power(KW)374555110132185
Main extruder Power(KW)557590-110185220280-315
Screen exchanger160mm200mm250mm350mm400mm3000cm²
Staff requirement2-32-32-32-32-32-3
Overall size(L*W*H)9*5*410*5*412*5*413*6*413*6*413*6*4



Category: Tags: , , , , , , , , ,

Description

Product Description

Introducing our Single Stage PP/PE Film/Bags Pelletizing Line, a cutting-edge solution in the field of Plastic Recycling Machines. This line is specifically designed to transform clean PP/PE film into high-quality pellets, offering a new level of efficiency and value in the recycling process.

Product Functionality

Our Single Stage PP/PE Film/Bags Pelletizing Line is the perfect way to complete your PE film washing line. The line uses precision extrusion to transform clean PP/PE film into high-quality pellets that command higher values in the market. This is made possible by our patented Heat Wave Stabilization™ technology, which evenly distributes heat throughout the extruder barrel, ensuring efficient and consistent operation.

Working Principle

The working principle of our Single Stage PP/PE Film/Bags Pelletizing Line is straightforward and effective. The clean PP/PE film is fed into the extruder, where it is melted and then formed into pellets through a process known as “melt pelletizing” or “strand pelletizing”. The line includes a hydraulic assisted screen change to ensure uninterrupted operation, and a pressure release mechanism to remove excess water vapors from the washed PE film.

Technical Specifications

Our Single Stage PP/PE Film/Bags Pelletizing Line comes with the following specifications:

  • Model #: SJ-100
  • Screw Diameter: ⌀100mm
  • L/D: 20/32
  • Driving Motor: 45-55 KW
  • Output: 100-200 KG/H

For more detailed specifications, please refer to the Technical Specifications on our website.

Images

Single_Stage_PP_PE_Film_Bags_Pelletizing_Line_03

In conclusion, our Single Stage PP/PE Film/Bags Pelletizing Line is a state-of-the-art solution for plastic film recycling. It offers a cost-effective and efficient way to transform clean PP/PE film into high-quality pellets, contributing to a more sustainable and environmentally friendly plastic recycling industry.


WARRANTY

All recycling machines come with a 1 year limited warranty.
